The first part of this report looked at the size of the routing table and looked at some projections of its growth for both IPv4 and IPv6. However, the scalability of Border Gateway Protocol (BGP) as the Internet’s routing protocol is not just dependent on the number of prefixes carried in the routing table.

Dynamic routing updates are also part of this story. If the update rate of BGP is growing faster than we can deploy processing capability to match then the routing system will lose coherence, and at that point, the network will head into periods of instability.

This report will look at the profile of BGP updates across 2022 to assess whether the stability of the routing system, as measured by the level of BGP update activity, is changing.

IPv4 stability

Figure 1 shows the daily BGP update activity as seen at AS131072, since mid-2009.

Figure 1 — IPv4 BGP update counts.
Figure 1 — IPv4 BGP update counts.

The number of observed BGP withdrawal messages per day (shown in violet in Figure 1) has remained relatively constant at some 15,000 – 20,000 withdrawals per day up until mid-2022. The daily rate increased to some 75,000 withdrawals at that time and has then been declining across the remainder of 2022 to reach some 50,000 withdrawals per day by the end of the year. The total number of advertised IPv4 prefixes has risen from 300,000 to 950,000 in the period from the start of 2011 until the end of 2022 (shown in orange in Figure 1).

There is no particular reason why the daily withdrawal count should be steady while the number of announced prefixes has tripled. If withdrawals are a result of some form of link-based isolation event at the origin of the announcement, then one would expect that as the number of networks increases the withdrawal volume would also increase proportionately, but this is not what we see in BGP. The withdrawal rate also appears to be unrelated to either the number of routed prefixes or the number of routed networks. There is no compelling explanation for this routing behaviour that I am aware of.

The number of update messages per day (shown in green in Figure 1) has not been as constant. This was steady at some 50,000 updates per day from 2009 until 2013. During 2013 the volume of updates grew to some 100,000 updates per day, which it maintained for most of the ensuing 24 months. During 2018, the number of updates per day rose again, approaching some 250,000 updates per day by the end of 2018. The update count remained around this level until the start of 2021. Through 2021 the update rate has declined to an average value of around 200,000 updates per day. It has maintained this level through 2022. To illustrate these trend movements in the BGP update rate, a smoothed average of the daily update count is shown in Figure 2.

Figure 2 — Smoothed IPv4 BGP prefix update counts.
Figure 2 — Smoothed IPv4 BGP prefix update counts.

It was fortuitous that the BGP update rate had been held steady for so many years, as this implied that the capability of BGP systems did not require constantly increasing processing capability. In the same way that there was no clear understanding of why the BGP update rate was steady for so many years, it’s also unclear why the rate increased and then declined in recent years.

What is also intriguing is that most of these prefix update messages are generated from a pool of between 30,000 to 80,000 prefixes. A plot of the daily count of prefixes that are the subject of BGP updates is shown in Figure 3. While this number is rising, it is not rising at the same rate as the number of updates per day, so the heightened instability is possibly due to more updates reaching convergence, rather than due to more unstable prefixes.

Another possible explanation is that we are looking at daily average numbers, and this rise in the average could be caused by a small pool of unstable prefixes exhibiting higher levels of instability than was the case previously.

Figure 3 — IPv4 unstable prefixes per day.
Figure 3 — IPv4 unstable prefixes per day.

The number of unstable prefixes per day appears to be gradually increasing over the years. A least-squares best fit shows a linear trend where the average daily unstable prefix count is increasing by some 4,000 prefixes per year. This is far lower than the trend in the increase in the size of the Forwarding Information Base (FIB) table. It is interesting to note at the end of 2022 the number of unstable prefixes has fallen over December 2022, while the number of BGP announcements has risen.

The long-term trend of an increasing count of the number of unstable prefixes and the increasing update count is not reflected in the measure of the time to reach a converged state (this is the period of time for the routing protocol to reach a converged state for a given prefix). The daily average time for an unstable prefix to reach stability is between 40 to 50 seconds (Figure 4). There was a period of elevated instability in 2019 to 2020 where the average convergence time rose to 80 seconds; it has since stabilized to a time of 45 seconds for the latter half of 2022.

Figure 4 — IPv4 average routing convergence time per day.
Figure 4 — IPv4 average routing convergence time per day.

The instability in BGP is not uniform. Half of all BGP updates during December 2022 are attributed to less than 10% of the unstable prefixes, and just 50 origin Autonomous System Numbers (ASNs) accounted for one-half of all BGP IPv4 updates in this period. It appears that the network is generally highly stable and that a very small number of prefixes appear to be advertised with highly unstable BGP configurations over periods that extend for weeks rather than hours.

The cumulative distribution of BGP updates by prefix and by origin-AS, shown in Figures 5 and 6, shows the highly skewed nature of unstable prefixes in the routing system. Also interesting is that the ASN distribution is more ‘skewed’ than that of the prefix distribution. This would tend to suggest that the cases of high update volume are generated at the network level rather than the individual prefix level.

Figure 5 – Distribution of BGP updates by prefix.
Figure 5 — Distribution of BGP updates by prefix.
Figure 6 — Distribution of BGP updates by origin-AS.
Figure 6 — Distribution of BGP updates by origin-AS.

IPv6 stability

Ideally, the IPv6 routing network should be behaving in a very similar manner to the IPv4 environment. It is a smaller network, but the underlying connectivity for IPv6 should be essentially similar in terms of the connectivity of IPv4 (it would be unusual to see two networks where one provided transit services to the other in IPv4, yet the opposite arrangement is used for IPv6). So, given that the underlying topology should have strong elements of similarity across the two protocols, we should see the BGP stability profile of IPv6 appear to be much the same as IPv4. However, this is not the case.

Figure 7 shows the profile of IPv6 updates since 2009. The IPv6 BGP network appears to be far ‘noisier’ as compared to the IPv4 network. The number of withdrawals and updates appears to follow the total size of the IPv6 FIB table. This shows some pathological instability in parts of the IPv6 network, which may be due to some form of BGP route oscillation that fails to converge.

Figure 7 — IPv6 BGP update counts.
Figure 7 — IPv6 BGP update counts.

Figure 8 shows that the number of unstable prefixes has changed since the start of 2018. From 2011 until the start of 2018 the number of unstable prefixes was tracking the total IPv6 table count, with some 10% of announced prefixes being updated each day. This jumped to 20% at the start of 2018. The high count of updated prefixes suggests a topology-based oscillation in one of the upstream feeds for this network that appears to affect a large subset of the total count of prefixes in the IPv6 routing table. This instability was partially addressed in 2020 but has since returned in the latter months of 2022.

An issue with running two discrete routing systems within the Internet is that it is sometimes the case that operational attention remains fixated on the IPv4 routing system, while IPv6 is simply assumed to be working. Routing pathologies in the IPv6 network appear to remain unnoticed for many months, and for the end user level, the dual-stack environment simply masks the issues. Failure to connect in IPv6 is silently fixed in applications’ Happy Eyeballs behaviour mode by rapidly switching to use IPv4 for the affected sessions when IPv6 reachability is impaired in some way.

Figure 8 — Unstable IPv6 prefix count.
Figure 8 — Unstable IPv6 prefix count.

The average time to reach convergence has been unstable for the IPv6 network (Figure 9). The daily average of this convergence time ranges between 40 and 100 seconds across 2022.

Figure 9 — IPv6 average routing convergence time per day.
Figure 9 — IPv6 average routing convergence time per day.

The distribution of updates in IPv6 is now very similar to IPv4. The distribution of updates in IPv6 by prefix and IPv6 by origin-AS is shown in Figures 10 and 11. For December 2022, the ‘noisiest’ 0.1% of ASes in IPv6 is associated with 35% of all updates, while the most active 0.1% of prefixes are associated with 28% of all updates.

Figure 10 — Distribution of BGP IPv6 updates by prefix.
Figure 10 — Distribution of BGP IPv6 updates by prefix.
Figure 11 — Distribution of BGP IPv6 updates by origin AS.
Figure 11 — Distribution of BGP IPv6 updates by origin-AS.

It is not immediately obvious why IPv6 has a larger instability component than IPv4. A concern is that this instability remains a persistent condition as the IPv6 network continues to grow, which would create a routing environment that would impose a higher processing overhead than we had anticipated, with its attendant pressures on BGP processing capabilities in the network.

Instability and topology

BGP is a distance vector routing protocol that achieves a coordinated stable routing state through repeated iterations of a local update protocol. The efficiency of the protocol depends heavily on the underlying topology of the network. Highly clustered topologies, such as star-based topologies, will converge quickly, whereas arbitrary mesh-based topologies will generally take longer to converge to a stable state.

The convergence behaviour of BGP, particularly in the IPv4 network, is quite remarkable and perhaps the best illustration of why this is the case lies in the average AS-PATH length of the BGP routing table over time (Figure 12).

Figure 12 — Average AS-PATH length of BGP IPv4 prefixes.
Figure 12 — Average AS-PATH length of BGP IPv4 prefixes.

A related picture is shown in the distribution of AS adjacency counts in the IPv4 network (Figure 13). Only nine networks have more than 1,000 AS adjacencies that are advertised to the transit network. This is consistent with a network that is composed of a relatively small set of transit ‘connectors’ and a far larger set of stub networks that attach themselves to this core.

Figure 13 — Distribution of AS adjacencies in the IPv4 network.
Figure 13 — Distribution of AS adjacencies in the IPv4 network.

 A similar picture exists in IPv6 (Figure 14) of a relatively stable average AS-PATH length, and there is a similar picture of AS adjacency distribution (Figure 15). In the case of IPv6, there are other factors that appear to influence the overall stability of IPv6.

Figure 14 — Average AS-PATH length of BGP IPv6 prefixes.
Figure 14 — Average AS-PATH length of BGP IPv6 prefixes.
Figure 15 — Distribution of AS adjacencies in the IPv6 network.
Figure 15 — Distribution of AS adjacencies in the IPv6 network.

These profiles of topology would support the conclusion that the IPv4 and IPv6 BGP systems should behave in a reasonably similar manner, yet IPv6 is visibly less stable.

However, the distributions of Figures 10 and 11 need to be remembered. When we are talking about average update volumes, we are actually talking about a very small set of prefixes that generate anomalously high numbers of updates. When we say ‘IPv6 is visibly less stable’, it is probably more accurate to say that ‘the small number of anomalously unstable prefixes in IPv6 exhibit relatively higher levels of instability than their IPv4 counterparts’.

Instability and update types

We can look further into these updates to see if there is any visible correlation between routing practices by network operators and BGP instability. If we look at just those updates that refine an already announced address prefix, then we can use a taxonomy of the effect of the routing update. The taxonomy used here is to look at a change in the origin-AS, a change in the next-hop AS (the next AS in the AS-PATH that is adjacent to the origin-AS), a change in the AS prepending of the AS-PATH, any other changes in the AS-PATH, and finally a change in the non-AS-PATH attributes of the update.

The profile of the daily count of these updates for IPv4 is shown in Figure 16 for IPv4. Changes to the origination of prefixes are uncommon. The most common changes are related to internal topology changes in the network (AS-PATH change) and changes in stub-to-transit connections (AS next-hop), which presumably are often related to traffic engineering changes.

Figure 16 — Distribution of update types in the IPv4 network.
Figure 16 — Distribution of update types in the IPv4 network.

A very similar profile is visible in the IPv6 network, with AS-PATH changes and AS next-hop changes being a major part of the update profile. In absolute terms, the volume of path change and next-hop changes are comparable and sometimes greater than the IPv4 measurements. Don’t forget that the IPv4 routing table was some 1M entries in recent months, as compared to the 150,000 entries in IPv6, so this instability of IPv6 network topology is up to six times greater than IPv4 on some days!

Figure 17 — Distribution of update types in the IPv6 network.
Figure 17 — Distribution of update types in the IPv6 network.

Another way of looking at this data is to remove the absolute volume of updates and look at the update types as a proportion of the total number of updates seen each day (Figures 18 and 19).

Figure 18 — Relative distribution of update types in the IPv4 network.
Figure 18 — Relative distribution of update types in the IPv4 network.
Figure 19 — Relative distribution of update types in the IPv6 network.
Figure 19 — Relative distribution of update types in the IPv6 network.

In IPv4, most (70%) of the BGP updates describe changes in the AS-PATH. Slightly less than 30% of the changes occur with the next-hop AS. IPv6 shows a similar update profile.

It is likely that much instability is due to BGP oscillation when negotiating routing policies relating to multiple paths. As a distributed algorithm, BGP itself is not a deterministic process, and when the protocol is attempting to negotiate a stable outcome between the BGP preferences of BGP speakers announcing reachability across multiple egress paths, and BGP listeners applying local preferences across a number of ingress paths, then some level of instability is not unexpected.

Indeed, what is perhaps most surprising here is that these BGP updates are so low, particularly when the underlying topology appears to show such a rich level of interconnection.

When a BGP environment becomes unstable and flips between multiple local states that are all equivalent one might expect that the BGP update rate would increase uncontrollably. What mitigates this situation is BGP’s Minimum Route Advertisement Interval (MRAI) damping interval. BGP will only emit updates every MRAI seconds, and only pass on the current state of each updated prefix at that time, damping out any form of higher frequency local route oscillation. The commonly used value of 27 to 30 seconds (varied randomly at each MRAI interval) is the most likely explanation of why BGP appears to be so well-behaved in terms of update rates.

The cost of this MRAI timer is reflected in the average time to route convergence, which is steady at 50 seconds in IPv4 (Figure 4) and varies between 40 and 50 seconds in IPv6 in a long-term oscillation with a period of months (Figure 9). From time to time, the discussion takes place on reducing the MRAI timer value for all eBGP speakers. Such a change could possibly result in faster average convergence times, but what is not so clear is the relationship between MRAI timer settings and overall BGP update volumes. It is likely that the widespread use of a smaller MRAI timer in the eBGP environment would result in an increased volume of BGP updates.

Instability and traffic engineering

BGP is used for two functions. The first is the maintenance of the network’s inter-domain topology. BGP ‘discovers’ the set of reachable networks through the conventional operation of a distance vector-style distributed routing protocol. It’s not that every BGP speaker assembles a complete map of the connected state of the network, BGP’s objective is slightly different in that each BGP speaker maintains a list of all reachable address prefixes and for each prefix maintains a next hop forwarding decision that will pass a packet closer to its addressed destination.

The second part of the use case can be more challenging. BGP is used to negotiate routing policies, or so-called ‘traffic engineering’. If a network is connected to two upstream transit providers and one offers a lower price than the other, then the local network may well prefer to use the lower-cost network for all outgoing traffic, all other things being equal. There is also the issue of incoming traffic that needs to be considered, so the local network operator would like to bias the route selection policies of all other networks such that the lower-cost transit network is used to reach this local network.

Outgoing traffic can be groomed to match local policies by using local policy settings in the interior routing space, but incoming traffic can only be ‘groomed’ by using BGP to bias other networks’ route selection policies.

There are a number of ways of achieving this, but the basic observation is that if you wish to groom incoming traffic according to a number of different policy settings then you need to advertise a collection of address prefixes to be associated with each policy setting.

The most common routing practice is to advertise the aggregate route set to all adjacent peers, and then selectively advertise more specific routes to some adjacent peers in order to implement these routing policies. What we would expect to see in this scenario is that the aggregate routes and the more specifics may well have differing AS paths, but they would share the same origin-AS.

A variant of this form of traffic engineering exploits the fact that the BGP route selection algorithm will prefer shorter AS paths when all other factors are equal. A BGP speaker may elect to artificially increase the AS-PATH length on the less preferred ingress path by adding repetitions of its own AS to the AS-PATH to the less preferred eBGP peer. Any form of instability in path selection between these multiple ingress paths would be reflected as a set of updates that retain the same origin-AS and even the same next-hop AS and retain the same sequence of ASes in the AS-PATH, but the paths differ across successive updates in the amount of AS prepending contained with the path.

A somewhat different scenario occurs when an end site uses an address prefix from a provider’s address block but wants to define a unique routing policy. In this case, the end site would use its own ASN, so that the aggregate and its more specific would use different origin-AS numbers.

It is also possible that the network operator is advertising more specific routes as a means of mitigating, to some small extent, the impacts of a hostile route hijack. In this case, the aggregate route and the more specific would share a common origin-AS and a common AS-PATH.

We can look at the routing table to see the prevalence of each of these types of advertised prefixes. Figure 20 shows the relative proportion of the prevalence of each of these four types of route advertisement:

  • A ‘root’ prefix that has no covering aggregate.
  • A ‘hole’ prefix where the origin-AS of the more specific prefix differs from the origin-AS of the covering aggregate.
  • A ‘path’ prefix where the more specific prefix shares the same origin-AS, but has a different AS-PATH.
  • A ‘more specific’ prefix where the AS-PATH of the more specific and the covering aggregate is the same.
Figure 20 — Relative distribution of prefix types in the IPv4 network.
Figure 20 — Relative distribution of prefix types in the IPv4 network.

Over the past decade, the proportion of root prefixes has declined slightly, as have hole prefixes, while the number of paths (different path, more specific) prefixes has risen slightly. The high proportion of path prefixes points to the prevalent use of more specifics in the IPv4 network for traffic engineering purposes.

A comparable view of the IPv6 network (Figure 21) shows a similar result in the profile of prefixes, but with some somewhat different starting conditions. The relative incidence of root prefixes has declined from 95% to 40%, while the number of path-distinguished more specific prefixes has risen from 10% to 35%. A possible explanation is that as IPv6 changes from being a low-use trial platform to becoming part of the service environment, then considerations of traffic engineering rise in importance. The number of a different path, more specific prefixes reflects this changing perception of the role of the IPv6 network.

This data points to the emerging picture of handling IPv6 addresses in a similar way to that used for IPv4, where there is widespread use of more specifics for both traffic engineering and as a rudimentary form of anti-hijacking defence.

Figure 21 — Relative distribution of prefix types in the IPv6 network.
Figure 21 — Relative distribution of prefix types in the IPv6 network.

Are each of these prefix types equally likely to be the subject of BGP updates? Or are some prefix types more stable than others? An intuitive guess would see root prefixes being more stable than traffic engineering prefixes, as would the hole-punching more specific prefixes. The other two types of more specific prefixes should be more likely to be unstable.

Figure 22 — Relative distribution of prefix update types in the IPv4 network.
Figure 22 — Relative distribution of prefix update types in the IPv4 network.

Figure 22 shows the day-to-day calculation of the relative proportion of BGP instability. It plots the number of updated prefixes per day of each prefix type, as compared to the total number of prefixes of that type.

It is a relatively noisy picture, but some general trends are visible. More specific prefixes that have the same AS-PATH as their covering aggregate are more likely to be updated as compared to other prefix types. Root prefixes and path prefixes (more specifics with different AS paths) appear to have a similar update ratio. Hole-punch more specifics (different origin-AS) are the most stable of the prefixes in the IPv4 network. In the latter part of 2022, the root prefixes are relatively more prevalent, coinciding with the higher incidence of updates in that period, as shown in Figure 1.

Figure 23 — Relative distribution of prefix update types in the IPv6 network.
Figure 23 — Relative distribution of prefix update types in the IPv6 network.

The same analysis has been applied to the IPv6 network (Figure 23). The relative incidence of updates shows that root prefixes are consistently more prevalent, while more specific and hole prefixes show considerable variation from day to day.

Conclusions

None of the BGP churn metrics indicate that we are seeing such an explosive level of growth in the routing system that it will fundamentally alter the viability of carrying a full BGP routing table anytime soon.

The BGP update activity is growing in both the IPv4 and IPv6 domains. The ‘clustered’ nature of the Internet, where the diameter of the growing network is kept constant while the density of the network increases implies that the dynamic behaviour of BGP, as measured by the average time to reach convergence, has remained very stable in IPv4 and has improved for IPv6 in the latter part of 2022.

The incidence of BGP updates appears to be largely unrelated to changes in the underlying model of reachability, and more related to the adjustment of BGP to match traffic engineering policy objectives. The growth rates of updates are not a source of any great concern at this point in time.
