How to: Build an XDP based BGP peering router

By on 30 Apr 2020

Category: Tech matters

Tags: , , , ,

1 Comment

Blog home

Over the last few years, we’ve seen an increase in projects and initiatives to speed up networking in Linux. Because the Linux kernel is slow when it comes to forwarding packets, folks have been looking at userland or kernel bypass networking.

In my last few posts, I’ve looked at examples of this, mostly leveraging DPDK to speed up networking. The thinking here is, let’s just take networking away from the kernel and process them in userland. Great for speed, not so great for all the kernel network stack features that now have to be reimplemented in userland.

Read: Kernel bypass networking with FD.io and VPP

The Linux kernel community has recently come up with an alternative to userland networking, called eXpress Data Path (XDP), which tries to strike a balance between the benefits of the kernel and faster packet processing.

In this post, I’ll take a look at what it would take to build a Linux router using XDP. I will go over what XDP is, how to build an XDP packet forwarder combined with a BGP router, and of course, look at the performance.

What is XDP?

XDP is an extended Berkeley Packet Filter (eBPF) based high-performance data path merged in the Linux kernel since version 4.8. Yes, BPF, the same packet filter you’re likely familiar with from tcpdump filters, though that’s now referred to as Classic BPF.

eBPF has gained a lot of popularity over the last few years within the Linux community. It allows you to connect to Linux kernel hook points; each time the kernel reaches one of those hook points, it can execute an eBPF program.

I’ve heard some people describe eBPF as what Java script was for the web, an easy way to enhance the web, or in this case, the kernel.

With BPF you can execute code without having to write kernel modules. XDP, as part of the BPF family, operates early on in the kernel network code. The idea behind XDP is to add an early hook in the RX path of the kernel and let a user-supplied eBPF program decide the fate of the packet.

The hook is placed in the network interface controller (NIC) driver just after the interrupt processing and before any memory allocation needed by the network stack itself. So all this happens before a Socket Buffer (SKB, the most fundamental data structure in the Linux networking code) is allocated. Practically, this means this is executed before things like tc and iptables.

A BPF program is a small virtual machine; perhaps not the typical virtual machines you’re familiar with, but a tiny (RISC register machine) isolated environment. Since it’s running in conjunction with the kernel, there are some protective measures that limit how much code can be executed and what it can do. For example, it cannot contain loops (only bounded loops), and there are a limited number of eBPF instructions and helper functions. The maximum instruction limit per program is restricted to 4,096 BPF instructions, which, by design, means that any program will terminate quickly. For kernels newer than 5.1, this limit was lifted to 1 million BPF instructions.

When and where is the XDP code executed

XDP programs can be attached to three different points.

The fastest, ‘offload mode’, is to have it run on the NIC itself. For that you need a smartnic. To the best of my knowledge, this is currently only supported on Netronome cards.

The next attachment opportunity is essentially in the driver before the kernel allocates an SKB. This is called ‘native mode’ and means you need your driver to support this; luckily most popular drivers do nowadays.

Finally, there is SKB, or ‘generic mode’ XDP, where the XDP hook is called from netif _ receive _ skb(); this is after the packet DMA and skb allocation are completed (as a result, you lose most of the performance benefits).

Assuming you don’t have a smartnic, the best place to run your XDP program is in native mode as you’ll really benefit from the performance gain.

XDP actions

Now that we know that XDP code is an eBPF C program, and we understand where it can run, now let’s take a look at what you can do with it.

Once the program is called, it receives the packet context and from that point on you can read the content, update some counters, and potentially modify the packet. Then the program needs to terminate with one of 5 XDP actions:

XDP_DROP

This does exactly what you think it does; it drops the packet and is often used for XDP based firewalls and DDOS mitigation scenarios.

XDP_ABORTED

This is similar to DROP, but indicates something went wrong when processing. This action is not something a functional program should ever use as a return code.

XDP_PASS

This will release the packet and send it up to the kernel network stack for regular processing. This could be the original packet or a modified version of it.

XDP_TX

This action results in bouncing the received packet back out the same NIC it arrived on. This is usually combined with modifying the packet contents, like, for example, rewriting the IP and Mac address, such as for a one-legged load balancer.

XDP_REDIRECT

The redirect action allows a BPF program to redirect the packet somewhere else, either a different CPU or different NIC. I’ll use this function later to build our router. It is also used to implement AF_XDP, a new socket family that solves the high-speed packet acquisition problem often faced by virtual network functions. AF_XDP is, for example, used by IDS and now also supported by Open vSwitch.

Building an XDP based high-performance router

Alright, now that we have a better idea of what XDP is and some of its capabilities, let’s start building!

My goal is to build an XDP program that forwards packets at line-rate between two 10G NICs. I also want the program to use the regular Linux routing table. This means I can add static routes using the ‘ip route’ command, but it also means I could use an opensource BGP daemon such as Bird or FRR.

I’ll jump straight to the code. I’m using the excellent XDP tutorial code to get started. I forked it here, but it’s mostly the same code as the original. This is an example called ‘xdp_router’ and uses the bpf_fib_lookup() function to determine the egress interface for a given packet using the Linux routing table. The program then uses the action bpf_redirect_map() to send it out to the correct egress interface. You can see the code here. It’s only a hundred lines of code to do all the work.

After I compiled the code (just run make in the parent directory), I load it using the ./xdp_loader program included in the repo and use the ./xdp_prog_user program to populate and query the redirect_params maps.

#pin BPF resources (redirect map) to a persistent filesystem
mount -t bpf bpf /sys/fs/bpf/

# attach xdp_router code to eno2
./xdp_loader -d eno2 -F — progsec xdp_router
# attach xdp_router code to eno4
./xdp_loader -d eno4 -F — progsec xdp_router

# populate redirect_params maps
./xdp_prog_user -d eno2
./xdp_prog_user -d eno4

Test setup

So far, so good. I’ve built an XDP based packet forwarder! For each packet that comes in on either network interface, eno2 or eno4, it does a route lookup and redirects it to the correct egress interface, all in eBPF code. All in a hundred lines of code! Pretty awesome, right?!

Now let’s measure the performance to see if it’s worth it. Below is the test setup.

Figure 1 — Test setup.
Figure 1 — Test setup.

I’m using the same traffic generator as before to generate 14Mpps at 64Bytes for each 10G link. Below are the results:

Flowspps per directionpps totalcores usedconfigured Queues
one direction14.6M4.6M12
bi-directional14.3M8.6M22
one direction1000014M14M44
bi-directional1000014M28M59

Table 1 — XDP forwarding test results.

The results are amazing! A single flow in one direction can go as high as 4.6 Mpps, using one core. Earlier, we saw the Linux kernel can go as high as 1.4Mpps for one flow using one core.

14Mpps in one direction between the two NICs require four cores. My earlier blog post showed that the regular kernel would need 16 cores to do this work!

Figure 2 — Test result: XDP forwarding using XDP_REDIRECT; 5 cores to forward 29Mpps.
Figure 2 — Test result: XDP forwarding using XDP_REDIRECT; 5 cores to forward 29Mpps.

Finally, for the bidirectional 10,000 flow test, forwarding 28Mpps, you need five cores. All tests are significantly faster than forwarding packets using the regular kernel, and all that with minor changes to the system.

Just so you know

Since all packet forwarding happens in XDP, packets redirected by XDP won’t be visible to IPtables or even tcpdump. Everything happens before packets even reach that layer, and since we’re redirecting the packet, it never moves higher up the stack. So, if you need features like network access control lists (ACLs) or Network Address Translation (NAT), you will have to implement that in XDP (take a look at the Cilium Project).

A word on measuring CPU usage

To control and measure the number of CPU cores used by XDP, I’m changing the number of queues the NIC can use.

I increase the number of queues on my XL710 Intel NIC incrementally until I get a packet loss-free transfer between the two ports on the traffic generator. For example, to get 14Mpps in one direction from port 0 to 1 on the traffic generator through our XDP router, which was forwarding between eno2 and eno4, I used the following setting:

ethtool -L eno2 combined 4
ethtool -L eno4 combined 4

For the 28Mpps testing, I used the following:

ethtool -L eno2 combined 9
ethtool -L eno4 combined 9

A word of caution

Interestingly, increasing the number of queues, and thus using more cores, appears to, in some cases, have a negative impact on efficiency. That is to say I’ve seen scenarios when using 30 queues, where the uni-directional 14Mps test with 10,000 flows appears to use almost no CPU (between 1 and 2) while the same test bidirectionally uses up all 30 cores. When restarting this test, I see some inconsistent behaviour in terms of CPU usage, so I’m not sure what’s going on — I will need to spend a bit more time on this later.

XDP as a peering router

The tests above show promising results, but one major difference between a simple forwarding test and a real-life peering router is the number of routes in the forwarding table. So, the question we needed to answer was “How will the bpf_fib_lookup function perform when there are more than just a few routes in the routing table?”. Or, more concretely, “Could you use Linux with XDP as a full route peering router?“.

To answer this question, I installed bird as a BGP daemon on the XDP router. Bird has a peering session with an exabgp instance, which I loaded with a full routing table using mrt2exabgp.py and MRT files from RIPE RIS

And, just to be a real peering router, I also filtered out the RPKI invalid routes using rtrsub. The end result is a full routing table with about 800K routes in the Linux forwarding information base (FIB).

Figure 3  — Test result: XDP router with a full routing table; 5 cores to forward 28Mpps.
Figure 3 — Test result: XDP router with a full routing table; 5 cores to forward 28Mpps.

After rerunning the performance tests with 800K BGP routes in the FIB, I observed no noticeable decrease in performance.

This indicates that a larger FIB table has no measurable impact on the XDP helper bpf_fib_lookup. This is exciting news for those interested in a cheap and fast peering router.

So what have I learnt?

XDP is a subset of the recent eBPF developments focused specifically on the hooks in the network stack. I went over the different XDP actions and introduced the redirect action, which, together with the bpf_fib_lookup helper allows us to build the XDP router.

When looking at the performance, I found that I can speed up packet forwarding in Linux by roughly five times in terms of CPU efficiency compared to regular kernel forwarding. I observed that I needed about five cores to forward 28Mpps bidirectionally between two 10G NICs.

When I compare these results with the results from my last blog post, DPDK and VPP, I see that XDP is slightly slower: 3 cores (VPP) vs 5 cores (XDP) for the 28Mpps test. However, the nice part about working with XDP was that I was able to leverage the Linux routing table out of the box, which is a major advantage.

The exciting part is that this setup integrates natively with Netlink, which allowed us to use Bird, or really any other routing daemon, to populate the FIB. I also saw that the impact of 800K routes in the FIB had no measurable impact on performance.

The fib_lookup helper function allowed us to build a router and leverage well-known userland routing daemons. I would love to also see a similar helper function for conntrack, or perhaps some other integration with Netfilter. It would make building firewalls and perhaps even NAT a lot easier. Punting the first packet to the kernel, and subsequent packets are handled by XDP.

Wrapping up, I started with the question, “Can you build a high-performance peering router using XDP?” The answer is yes, you can build a high-performance peering router using just Linux and relying on XDP to accelerate the data plane, while leveraging the various open-source routing daemons to run your routing protocols. That’s exciting!

Adapted from original post which appeared on Medium.

Andree Toonk is Senior Manager Network Engineering at OpenDNS, now Cisco Cloud Security, and Founder of BGPMon.
