On 3 January 2024, Spain’s second-largest mobile operator, Orange España, experienced a national outage spanning multiple hours. The cause? A compromised password and an increasingly robust routing system. It turns out that the network operator’s favourite defence tool (RPKI) can be a double-edged sword.

Using a password found in a public leak of stolen credentials, a hacker was able to log into Orange España’s RIPE NCC portal using the password “ripeadmin”. Oops! Once in, this individual began altering Orange España’s RPKI configuration, rendering many of its BGP routes RPKI-invalid.

As demonstrated in Kentik’s earlier analysis, the Internet’s RPKI Route Origin Validation (ROV) deployment has reached the point where the propagation of a route is cut in half or more when evaluated as RPKI-invalid. Normally this is the desired behaviour, but when an RPKI config is intentionally loaded with misconfigured data, it can render address space unreachable, effectively becoming a tool for denial of service.

Figure 1 — Aggregate data from the outage.
Figure 1 — Aggregate data from the outage.

Using Kentik’s aggregator NetFlow, we observed the outage (illustrated above) as a large drop in the volume of inbound traffic to Orange España (AS12479) between 14:20 UTC (3:20pm local) and 18:00 UTC (7pm local). However, there were more developments before this window of time as well as some lingering effects, which we will dig into in the post below.

What happened?

We already know the outage took place and how the attacker pulled it off. Now let’s trace the sequence of events using archived RPKI data from RPKIviews.

The story begins at 09:28 UTC on 3 January 2024, when someone (presumably the attacker) began tinkering with publishing and revoking Route Origin Authorizations (ROAs) for IP ranges belonging to the Spanish mobile operator. Then, at 09:42 UTC they published three new ROAs for Orange España IP ranges with material impact.

Origin	prefix		maxLength	ta	expiration
AS12479	93.117.88.0/22	22		ripe	1704355258
AS12479	93.117.88.0/21	21		ripe	1704355258
AS12479	149.74.0.0/16	16		ripe	1704355258

Source

Given the fact that 93.117.88.0/22, 93.117.88.0/21, and 149.74.0.0/16 were all already originated by AS12479, those routes weren’t affected, but 149.74.0.0/16 had quite a few more-specifics that were now going to be evaluated as RPKI-invalid due to the max prefix length setting of 16.

Perhaps realizing this, minutes later, someone published a slew of additional ROAs to account for the more-specifics of 149.74.0.0/16. These had the proper origin (AS12479) and as a result, all of those more-specifics became valid. All but one, that is.

Origin	prefix		maxLength	ta	expiration
AS12479	149.74.100.0/23	23		ripe	1704355258
AS12479	149.74.102.0/23	23		ripe	1704355258
AS12479	149.74.104.0/23	23		ripe	1704355258
AS12479	149.74.106.0/23	23		ripe	1704355258
AS12479	149.74.108.0/23	23		ripe	1704355258
(and many more)

Using Kentik’s BGP visualization, we can compare the impact in reachability (aka propagation) for two adjacent more-specifics of 149.74.0.0/16. As shown in Figure 2, 149.74.172.0/22 was the route missed in that follow-up publication of ROAs. Its reachability dropped over four hours to as little as 20% of our BGP sources.

Figure 2 — Outage impact adjacents.
Figure 2 — Outage impact adjacents.

Conversely, the rest of the more specifics looked like 149.74.168.0/22 — a brief partial drop in reachability between the first and second publications of ROAs mentioned above.

Figure 3 — Brief partial drop in reachability.
Figure 3 — Brief partial drop in reachability.

Although these prefixes were RPKI-invalid for several minutes, they only experienced a partial drop in reachability due to delays in the time to globally propagate ROAs, as documented in recent research on the topic. The act of blotting out a newly RPKI-invalid route is not instantaneous.

Wielding RPKI as a weapon

Then the attacker took it a step further by creating ROAs with an origin other than that of Orange España’s. At about the same time, those additional ROAs were published covering the more specifics of 149.74.0.0/16, and four new ROAs were created for Orange España IP space with a deliberately incorrect origin of AS49581.

Origin	prefix		maxLength	ta	expiration
AS49581	149.74.0.0/16	16		ripe	1704355258
AS49581	1.178.232.0/21	21		ripe	1704355258
AS49581	145.1.240.0/20	20		ripe	1704355258
AS49581	62.36.0.0/16	16		ripe	1704355258

The addition of the bogus ROA for 149.74.0.0/16 had no effect because the attacker had previously created a ROA with the correct origin (AS12479) — as long as one ROA matches, a route is evaluated as RPKI-valid.

145.1.240.0/20 and 1.178.232.0/21 were only briefly invalid before the attacker published ROAs with correct origins.

Origin	prefix		maxLength	ta	expiration
AS12479	145.1.240.0/20	20		ripe	1704355258
AS12479	1.178.232.0/21	21		ripe	1704355258

Only 62.36.0.0/16 (shown below) and its numerous more specifics were rendered RPKI-invalid and had their reachability reduced for the duration of the outage due to the ROAs with bogus origins.

Figure 4 — Reachability was reduced with bogus origins.
Figure 4 — Reachability was reduced with bogus origins.

Thus far in the story, the attacker’s tinkering has led to the creation of a couple of RPKI-invalid routes and some minor reachability problems, but the major disruption was yet to come.

It wasn’t until about 14:20 UTC (3:20pm local) that things got ugly. The attacker went for it and published four more ROAs with bogus origins. Two of the ROAs were /12s, which covered over a thousand routes originated by AS12479 — all rendered RPKI-invalid by the publication of the following ROAs:

Origin	prefix		maxLength	ta	expiration
AS49581	85.48.0.0/12	12		ripe	1704355258
AS49581	90.160.0.0/12	12		ripe	1704355258
AS49581	93.117.88.0/21	21		ripe	1704355258
AS49581	145.1.232.0/21	21		ripe	1704355258

It was here when the traffic graph at the beginning of this blog post began to take a nose dive. The number of globally routed routes originated by AS12479 dropped from around 9,200 to 7,400, as backbone carriers that reject RPKI-invalid routes stopped carrying a large chunk of Orange España’s IP space.

Figure 5 — Reachability of 145.1.232.0/21 during the worst part of the outage.
Figure 5 — Reachability of 145.1.232.0/21 during the worst part of the outage.

It wasn’t until just before 18:00 UTC (7pm local) that things began to return to normal. Engineers from Spain’s second-largest mobile operator regained control of their RIPE NCC account and began publishing new ROAs that would enable the carrier to restore service.

Origin	prefix		maxLength	ta	expiration
AS12479	85.48.0.0/12	12		ripe	1704384768
AS12479	90.160.0.0/12	12		ripe	1704384768
AS12479	62.36.0.0/16	16		ripe	1704384768
AS12479	93.117.88.0/21	21		ripe	1704384768
AS12479	145.1.232.0/21	21		ripe	1704384768
AS12479	93.117.92.0/22	22		ripe	1704384768
AS12479	62.36.21.0/24	24		ripe	1704384768

Conclusion

While RPKI was employed as a central instrument of this attack, it should not be construed as the cause of the outage any more than we would blame a router if an adversary were to get ahold of the login credentials and start disabling interfaces.

It seems that before 3 January 2024, the Spanish mobile operator’s RIPE NCC account had never created a ROA (although other parts of Orange had created some on its behalf). If RPKI wasn’t on Orange España’s radar before, it sure is now.

Although the outage is over, there is still much clean-up work to be done. As of 4 January 2024, over a thousand of the routes originated by AS12479 are still invalid, mostly due to the max prefix length setting on the ROAs for the two /12s. Between 3 January and 4 January 2024, the number of unique IPv4 addresses originated by AS12479 dropped from 7M to 5M, and a few bogus ROAs with an origin of AS49581 are still in circulation.

Figure 6 — One of over a thousand newly RPKI-invalid routes still originated by AS12479.
Figure 6 — One of over a thousand newly RPKI-invalid routes still originated by AS12479.

I would remind engineers cleaning up those ROAs that max prefix length is an optional field and can simply be left empty causing RPKI to only match on the origin of the ROA. This course of action was recently published as a best current practice.

RIPE NCC, the Regional Internet Registry (RIR) responsible for managing the allocation and registration of Internet number resources (IP addresses and Autonomous System Numbers) in Europe, has launched an investigation into the incident.

Hopefully, this incident can serve as a wake-up call to other service providers that their RIR portal account is mission-critical and needs to be protected by more than a simple password.

Update

In our original blog post, I mentioned some ‘clean-up work’”’ that was still required to address a myriad of RPKI-invalid routes that were being originated by AS12479 due to the quick fix ROA modifications that resolved the outage.

These RPKI-invalid routes weren’t causing connectivity issues because three covering routes (85.48.0.0/12, 90.160.0.0/12, and 62.36.0.0/16) were RPKI-valid ensuring the address space was globally reachable.

Well, that clean-up work was accomplished at 16:00 UTC on 8 January, five days after the multi-hour outage. Orange España modified the ROAs for these three IP address ranges by increasing the maximum prefix length to 24 (from 12 and 16).

We can see the impact in BGP as the reachability of some of the formerly RPKI-invalid routes jumped once they were RPKI-valid and no longer being filtered. The graphic below shows how reachability through the upstreams of AS12479 (primarily Orange, AS5511 and Lumen, AS3356) changed over this time:

Orange Espana outage update

The change is also visible in Kentik’s aggregate NetFlow. Below is a graphic of traffic to AS12479 (in bits/sec) on 8 January colored by the RPKI evaluation of the destination address space.

There are three categories of traffic:

  1. RPKI-unknown (routes without ROAs)
  2. RPKI-valid (routes that match ROAs)
  3. RPKI-invalid, but covered (routes which are RPKI-invalid, but are reachable via a covering prefix)
Orange Espana outage update

We can see the ‘RPKI-invalid, but covered’ traffic, along the bottom in a faint yellow, drops away to zero once the changes to the ROAs are published and that traffic becomes RPKI-valid. Again, since there were RPKI-valid covering routes, there was no change in the overall volume of traffic reaching AS12479.
