Common folklore in the Domain Name System (DNS) is that a delegated domain name must be served by two or more nameservers. The logic for this is based on a desire for service resilience. If one server is unreachable, then hopefully, the other is not. Recursive resolvers, when presented with a list of two or more nameservers for a domain, will work through this list until they query a responsive nameserver.
This simple description raises a couple of questions. Firstly, when presented with a list of nameservers for a domain how do recursive resolvers respond? Do they send queries to all the nameservers at once? Or do they serialize their actions in looking for a responsive nameserver? Secondly, if these queries are serialised, then how can a domain administrator organise the zone’s nameservers to maximise both DNS resolution performance and service resilience?
Recent work
To assist with answering our questions there are a couple of recent(ish) papers that address parts of this topic. The first paper dates from 2017, “Recursives in the wild: Engineering Authoritative DNS Servers”, by a group of researchers at SIDN Labs and USC’s Information Sciences Institute. They motivate their study by observing that ‘To meet their goals of minimizing latency and balancing load across nameservers and anycast, operators need to know how recursive resolvers select an NS, and how that interacts with their nameserver deployments’. By the time that this work was undertaken the use of anycast in the DNS was a well-established operational practice, and the conclusion from the paper is that: “all nameservers in a DNS service for a zone need to be consistently provisioned (with reasonable anycast) to provide consistent low latency to users.”
There is a current Internet Draft document, “Secure Nameserver Selection Algorithm for DNS Resolvers” by researchers from Tsinghua University, Alibaba Cloud, and Salesforce that focuses on the behaviour of recursive resolvers. This draft provides a description of the nameserver selection algorithms used in several commonly used recursive resolvers (Bind 9, Unbound, Knot, PowerDNS, Microsoft DNS). This document also notes that: “Nameserver selection algorithms employed by DNS resolvers are not currently standardized in the DNS protocol”.
This is the case. The only reference to nameserver selection in the RFC series is in RFC 1034, which has the advice that “The sorting [of nameservers] … may involve statistics from past events, such as previous response times and batting averages.” (RFC 1034, “Domain Names – Concepts and Facilities, Paul Mockapetris, 1987). Yes, the term ‘batting average’ is used here, without further elucidation. Presumably, it means some record of responsiveness to respond to queries, although other interpretations are equally possible!
Some simple tests of resilient resolver behaviour
How do recursive resolvers behave when attempting to resolve a domain name served by multiple nameservers where none of the nameservers are responsive? Table 1 shows the behaviour of the Bind 9 resolver when presented with a variable collection of IPv4-only nameservers.
| Servers | Queries | Duration (secs) | Servers queried |
| 1 | 3 | 7.2 | 1 |
| 2 | 6 | 8.1 | 2 |
| 3 | 8 | 10.0 | 3 |
| 4 | 7 | 10.0 | 4 |
| 5 | 7 | 8.8 | 5 |
| 6 | 8 | 9.6 | 6 |
| 7 | 7 | 8.8 | 6 |
| 8 | 7 | 8.8 | 6 |
| 9 | 7 | 8.8 | 6 |
| 10 | 7 | 8.8 | 6 |
| 11 | 8 | 9.6 | 6 |
| 12 | 7 | 9.2 | 6 |
| 13 | 8 | 10.0 | 7 |
In the case of a single non-responsive nameserver, the resolver will halt after three queries, taking a total of 7.2 seconds. For more servers, the resolver appears to bring resolution to a halt after some 9 – 10 seconds. The resolver appears to query six nameservers, except for the case when there were 13 nameservers when seven nameservers were queried. In each case, the resolver was ‘cold started’ with a clear cache.
Does the picture change when using unresponsive dual-stacked nameservers? Table 2 shows the outcome of this test, and the results are largely the same.
| Servers | IPv4 queries | IPv6 queries | Queries | Duration (secs) | Servers queried |
| 1 | 3 | 3 | 6 | 8.0 | 1 |
| 2 | 4 | 3 | 7 | 8.1 | 2 |
| 3 | 4 | 4 | 8 | 9.6 | 3 |
| 4 | 5 | 3 | 8 | 9.7 | 4 |
| 5 | 3 | 4 | 7 | 8.8 | 5 |
| 6 | 3 | 5 | 8 | 9.6 | 6 |
| 7 | 3 | 6 | 9 | 8.8 | 5 |
| 8 | 2 | 6 | 8 | 8.8 | 5 |
| 9 | 3 | 4 | 7 | 8.8 | 6 |
| 10 | 4 | 5 | 9 | 10.0 | 6 |
| 11 | 3 | 4 | 7 | 8.8 | 6 |
| 12 | 4 | 4 | 8 | 9.6 | 6 |
| 13 | 5 | 7 | 12 | 10.0 | 7 |
The conclusion to be drawn from this measurement is that there is little to be gained in terms of resilience in using more than six nameservers when using Bind 9 as a recursive resolver.
Each recursive resolver implementation has chosen to implement failover and resilience in a different manner. Tables 3 and 4 show the results of the same experiment with unresponsive nameservers, using the Unbound recursive resolver.
| Servers | Queries | Duration (secs) | Servers queried |
| 1 | 11 | 46.6 | 1 |
| 2 | 21 | 55.4 | 2 |
| 3 | 37 | 331.7 | 3 |
| 4 | 52 | 327.7 | 4 |
| 5 | 65 | 428.4 | 5 |
| 6 | 72 | 360.0 | 6 |
| 7 | 21 | 131.6 | 2 |
| 8 | 63 | 534.5 | 6 |
| 9 | 107 | 533.5 | 9 |
| 10 | 110 | 230.4 | 10 |
| 11 | 109 | 395.6 | 11 |
| 12 | 135 | 541.6 | 12 |
| 13 | 124 | 188.8 | 13 |
| Servers | IPv4 queries | IPv6 queries | Queries | Duration (secs) | Servers queried |
| 1 | 10 | 11 | 21 | 84.2 | 1 |
| 2 | 13 | 11 | 24 | 229.1 | 2 |
| 3 | 33 | 12 | 45 | 336.4 | 3 |
| 4 | 28 | 16 | 44 | 391.2 | 4 |
| 5 | 61 | 51 | 112 | 735.5 | 5 |
| 6 | 57 | 61 | 118 | 585.3 | 6 |
| 7 | 63 | 43 | 106 | 258.5 | 6 |
| 8 | 71 | 78 | 149 | 1,577.0 | 7 |
| 9 | 67 | 47 | 114 | 177.5 | 8 |
| 10 | 66 | 48 | 114 | 717.8 | 8 |
| 11 | 79 | 58 | 137 | 203.6 | 9 |
| 12 | 67 | 62 | 129 | 223.1 | 8 |
| 13 | 67 | 62 | 129 | 246.5 | 9 |
Clearly Unbound is a far more persistent algorithm, spacing out its queries in increasing intervals (increasing in doubling steps with 3, 6, 12, and 24 seconds between queries) for some minutes. In general, stub resolvers typically stop waiting for a response from a recursive resolver after 10 seconds, so it is not exactly clear the incremental benefit of having the recursive resolver persist for many more minutes. It strikes me as a measure that has little, if any, positive features. The original querier has given up after 10 seconds, so no client is waiting for a response, and the additional queries to unresponsive nameservers appear to simply add to the level of DNS background noise.
There is also the additional worrisome issue of DNS amplification where a single query from a stub resolver to an Unbound recursive resolver can generate over 100 queries. In this age of acute sensitivity to various forms of denial-of-service vulnerabilities, this behaviour pattern appears to be far more of a harmful liability than a sign of virtuous persistence! I have no idea why the Unbound support folk still have this behaviour in their implementation. Bind 9’s approach of abandoning a resolution process after nine seconds appears to match stub resolver behaviour and shows an adequate level of persistence in attempting to deal with unresponsive nameservers.
Large-scale measurements of recursive resolver behaviour
Multiple nameservers are intended to provide both resilience and improved performance. There appears to be a general expectation that recursive resolvers have implemented some interpretation of the general objectives of nameserver selection and will attempt to prefer querying the recursive resolver with the fastest response. The following descriptions of recursive resolver nameserver selection are drawn from a current Internet Draft document, “Secure Nameserver Selection Algorithm for DNS Resolvers” by researchers from Tsinghua University, Alibaba Cloud and Salesforce.
Bind 9 uses an estimate of the Smoothed Round-Trip Time (SRTT) for each nameserver, and selects the nameserver with the lowest SRTT for the next query. Nameservers that have not been queried are assigned an initial SRTT of between 1 to 32 ms. Also, all nameservers that are not selected have their SRTT values decreased. Over time such nameservers will be selected and queried, and the SRTT value is reset to the actual query/response time as a result.
Unbound uses a different strategy. The resolver randomly selects from all candidate nameservers, excluding a nameserver from this candidate set only when its SRTT exceeds the fastest one by more than 400ms.
The Knot resolver attempts to balance a strong preference to use the closest nameserver, and a need to check on all other nameservers to see if the reachability of any of these nameservers has changed. In 95% of cases, a Knot resolver will query the lowest latency server and randomly choose from the other servers in 5% of cases.
PowerDNS applies a ‘decay’ function to the SRTT of each nameserver during each query, ensuring that with more cases the unused nameserver’s SRTT will decay to the point when it is the most preferred.
Let’s put this theory to the test by using a large-scale measurement of the interaction between recursive resolvers and authoritative servers. We will enrol recursive resolvers by using an advertisement-based measurement platform, presenting the measurement system with some 20M – 30M individual measurement cases per day. The measurement script presents the user’s system with a unique DNS name (so that caching cannot influence the results), where the name is drawn from a uniquely named domain that is served by four dual-stack unicast geographically dispersed nameservers.
The locations of each of these nameservers and the RTT path times between each pair of these servers are shown in Figure 1.
What we expect to see if recursive resolvers behave with a balance of performance and resilience would be for the resolver to have a strong ‘attachment’ to the nameserver that has the fastest DNS response times, and a regular periodic sweep across the other nameservers to confirm that the selected server remains the fastest to respond. A plot of the nameserver selection of this ‘ideal’ recursive resolver is shown in Figure 2. The servers labelled in the figure are in for Mumbai, eu for Frankfurt, am for Atlanta and ap for Singapore.
We can compare this idealized behaviour against a couple of widely used recursive resolver implementations. Figure 3 shows the query behaviour of a recursive resolver located in Australia, running Bind 9 when querying for names that are served by this measurement rig. Unlike the earlier tests when looking at the resilience behaviour of recursive resolvers, in this case, the nameservers are always reachable and responsive. The test generates unique-named queries at a rate of 1 per second and we are looking at the selection of a nameserver used to form the recursive resolver’s response.
Unbound, on the other hand, uses a nameserver selection algorithm with a far coarser level of granularity of 400ms. This roughly corresponds to the diameter of the public Internet, so in practice, the selection algorithm corresponds to a random choice with no bias to use faster resolvers. Figure 4 shows the behaviour of this test using a recursive resolver running Unbound 1.17.1.
In the case of the Unbound resolver, there is no strong signal that the resolver prefers to use the fastest nameserver. The RTT times for each of the servers are: 104ms for ap, 170 ms for in, 217 ms for eu and 278 ms for am. Why the resolver prefers to use the most distant server, am, in preference to the eu server is unclear to me.
Using the same technique, we can look at the two most popular open resolvers, the Google Public DNS service operated from 8.8.8.8 and Cloudflare’s 1.1.1.1 service. Both resolver services are operated as an anycast service, so the test system’s DNS query should reach an instance of the anycast set at a location close to the test system, in Australia. Repeated queries would be directed to a resolver located in a similar location as the initial resolver, which implies that if there is a bias toward maximising performance, then the recursive resolver would prefer to query the nearest server. What we observe for the Google service is shown in Figure 5 and in Figure 6 for the Cloudflare service.
It is evident that there is no strong attachment preference in the Google service. The nearest service, the ap service in Singapore is queried at a higher rate than the server located in Mumbai, and the servers in Frankfurt are queried less frequently, but the bias is not a pronounced one.
This relative preference is also visible in the Cloudflare 1.1.1.1 query profile, where the query volume appears to be inversely related to the RTT for each server relative to the original query location in Australia.
The larger scale measurement involved running the measurement over an 8-day period from 1 to 8 December 2024. We look at the resolvers that query the four nameservers in our measurement and use a similar presentation format as already used above to show the nameserver selection preference for each of the recursive resolvers.
The most used resolver is one operated by Bharti Airtel in India, a network that has an estimated 31M end users. The query distribution for a 60-minute period is shown in Figure 7.
At this level of granularity, it is evident that the resolver has a preference to direct queries to the Singapore server (ap), some 31 ms distant by RTT, not to the apparently closer server located in Mumbai, which has an RTT of 27 ms. The other server used by this resolver in Frankfurt is 145 ms distant. Curiously, there were no queries sent to the server located in Atlanta over this period.
The summary of the eight-day measurement period for this resolver is shown in Table 5. As the queries are not uniformly spread in time, instead of using a query count as an indicator of preference we’ll use a matric of an attachment time where the time interval between two successive queries to the same server is added to the total attachment time for that server. The attachment ratio is the relative amount of time the resolver was attached to this server.
| Server | Queries | Attachment time (secs) | Longest attachment interval (secs) | RTT (ms) | Attachment ratio |
| Atlanta | 87 | 1 | 0 | 243 | 0% |
| Singapore | 611,992 | 202,012 | 725 | 31 | 48% |
| Frankfurt | 581,799 | 183,051 | 637 | 145 | 44% |
| Mumbai | 300,751 | 32,153 | 580 | 27 | 8% |
This presentation clearly shows that this resolver, located in India, has an equal preference for query servers located in Singapore and Frankfurt.
This per-resolver attachment ratio now gives an approach to represent the attachment preference for the 100 resolvers that had the highest query counts in this measurement.
Each vertical line is the measurement for a single resolver, and the radius of the circles for each server is the attachment ratio. The larger the circle, the greater the attachment ratio. Figure 8 clearly shows a preference to query the servers located in Frankfurt and Singapore, but it is not clear whether this preference is based on the distribution of placement of advertisements or the underlying distribution of user populations.
Over these eight days, 166,580 resolver IP addresses were observed to query the domain name. To perform this form of query analysis for attachment it’s necessary, and for this, it is helpful to have a relatively dense sequence of queries. The top 1,000 resolver IP addresses that ask the most queries vary from 1,494,629 to 36,482 queries, or an average of one query every half a second to one query every twenty seconds over the eight days. This set of the top 1000 resolver IP addresses accounts for 27% of the total query volume.
If a resolver queries a single server for more than 60% of the time, then we will term this a ‘strong attachment’ query behaviour. A total of 616 resolver IP addresses show a strong attachment from this set of 1,000 resolvers. If no server has more than 40% of attachment time, then we can term this as ‘no attachment’ preference. A total of 53 resolver IP addresses show no attachment preference.
The next question is how good is this attachment preference? To perform this analysis, we can measure the RTT from each server to the resolver and compare the RTTs against the attachment result.
For example, the IPv6 address 2a01:e00:ffff:53:2::13 is a recursive resolver operated by the ISP Free.FR in France. The ping RTT measurements for this resolver IP address are: Atlanta — 95.3 ms, Singapore — 307.5 ms, Frankfurt — 9.8 ms, and Mumbai -—241.6 ms. If this resolver were to make an accurate selection of the closest server, then it would select the server located in Frankfurt. The queries made by this resolver show that the server located in Atlanta was used for 70% of the time, which is some 85ms more distant than the closest resolver. So, the ‘error’ in this resolver’s selection process is 85ms.
We can apply this technique to the 661 resolver IP addresses that show a strong attachment preference. Of the 661 resolvers, some 498 respond to ping requests. Of these 499 resolvers, 199 had made a strong attachment to the server with the lowest ping time (39%). The remaining 299 resolvers have selected a more distant resolver. The average error time interval for these resolvers was 142.3 ms. The distribution of these error values is shown in Figure 9. There is a strong signal of an error time of less than 120 ms, which is the case for 175 of these resolvers. The highest error value was 434 ms.
Conclusions
What is this data telling us?
A domain publisher cannot rely on the server selection algorithm used by today’s recursive resolvers to make an optimal selection from a dispersed set of unicast authoritative nameservers. If name resolution performance is an important factor, then the domain publisher needs to look to an anycast solution, preferably with a highly diverse collection of points of presence within the anycast constellation. Anycast pushes the responsibility of the nameserver selection process away from the recursive resolver and into the routing system. If the anycast distribution is sparse or concentrated in a small region, then the relatively coarse BGP route selection algorithm of AS Path Length may not produce optimal outcomes. Widely dispersed anycast networks will have a better outcome here.
How many nameservers are enough? If the domain is using anycast as a method to ensure the performance of name resolution, the major motivation behind the choice of the number of nameservers is that of resilience. Using two or more nameservers from the same anycast service platform achieves little in the way of additional resilience. A hybrid approach of using both anycast and unicast nameservers can improve resilience but at the cost of potential compromise in resolution performance through poor resolver selection of nameservers. There is a practical limit to the number of nameservers that most recursive resolvers will query, so the additional marginal improvement in resilience decreases with each additional nameserver when the domain is served by more than two nameservers, unicast or anycast.
This analysis suggests that the optimal approach for a domain when considering both performance and operational resilience is for the domain to be served by two distinct dual-stack diverse anycast nameservers.
If the domain being served is DNSSEC-signed using front-end-signers, then this advice needs some further qualification, as the scenarios related to key management and coordination between the two anycast platform providers can quickly become quite complex. But that scenario is perhaps best left to a future article!
